Thermally conductive adhesive

Thermally conductive adhesive application.

Cotronics® Duralco® Thermally Conductive Adhesives and potting compounds provide the heat dissipation required for many High Temperature Electronic and Industrial applications. These ultra-temperature adhesives combine Cotronics®’ unique polymer system and special thermally conductive fillers to provide continuous service up to 340°C. Duralco® conductive Adhesives have excellent adhesion to glass, ceramics, metals and plastics. Resistant to most chemicals and solvents.

Thermally conductive Epoxy Applications

Removing the heat generated in many electronic applications including semi-conductors, rectifiers, high power devices, etc.

Heat transfer applications, including bonding copper coils to reaction vessels for heating and or cooling. Heat tracing adhesive, etc.

Fabrication of heated, plastic forming tools, melds, etc.

Thermally conductive Epoxy Technical data

260°C - Duralco® 128

Hi-electrically Resistant Ceramic based Epoxy

Duralco® 128 is highly thermally conductive, electrically resistant adhesive and potting compound. The ceramic fillers are carefully chosen to provide high thermal conductivity and high dielectric strength. Just mix the resin and hardener, apply and cure at room temp. Curing may be accelerated with mild heat.

260°C - Duralco® 132

Hi-thermal Conductive Aluminium based Epoxy

Duralco® 132 is an Aluminium Metal Filled Epoxy that cures at room temperature to form machinable, thermally conductive bond lines. Duralco® provides the maximum heat transfer available in a 260°C epoxy system. Can be supplied as a non-sag putty, Duralco® 132P, for heat tracing applications.

260°C - Duralco® 133

High-temperature Aluminium based Epoxy

Duralco® 133 is a two component, heat curing, Aluminium Filled, Conductive Epoxy. Duralco® 133 combines the excellent properties of Duralco® 132 with Cotronics®’ higher temperature epoxy systems making it suitable for applications requiring up to 315°C service. Cures with mild heat to form thermally conductive bond lines and heat transfer medium. Duralco® 133 is suitable for high temperature tooling. It is readily machinable and ideal for all kinds of repairs and as a construction material.

260°C - Duralco® 134

Electrically Resistant Grease Ceramic based Epoxy

Duralco® 134 thermally conductive grease, is a non-hardening, electrically insulating and thermally conductive grease. It is ideal for use between components and heat sinks. Duralco® 134 retains its paste like consistency, enabling parts to be easily removed and replaced. Will not dry out even after long periods of time. Usable to 260°C.

260°C - Duralco® 135

Thermally Conductive Grease Aluminium based Epoxy

Duralco® 134 is filled with an ultra-fine, aluminium metal powder to provide the maximum possible heat transfer rate in a non-hardening grease. Used in delicate military applications where excess heat build-up can cause serious failures. Duralco® 135 is commonly used in many industrial applications where electrical resistance is not critical.

Thermally Conductive Epoxy (177.80k)

Technical Datasheet Cotronics® thermally conductive Epoxy.


Image générique

Duralco® 132 Adhesive epoxy

Cotronics Duralco ® 132 adhesive is a bonding epoxy resin for high temperature applications. It is used to make high temperature bonding, up to 260°C. This 2 components epoxy adhesive is charged with aluminum powder. This adhesive is a good electric conductor. This product is available in 450 and 900 grammes. For bigger packaging please contact us. We also offer other  thermally conductive adhesives for high temperature bonding.
Full description
Image générique

Duralco® 133 Adhesive epoxy

Cotronics Duralco ® 133 adhesive is a bonding epoxy resin . It is used to make high temperature bonding, up to 315°C. This 2 components epoxy adhesive is charged with aluminum powder. This adhesive is a good electric conductor. It needs a heat curing. This product is available in 0.23 litres.  For bigger packaging please contact us. We also offer other  thermally conductive adhesives  for high temperature bonding.
Full description
Image générique

Duralco® 134 Thermal Grease

Cotronics Duralco ® 134 is a ceramic based grease. It is a non-hardening product. It is ideal for use between components and heat sinks. Usable to 260°C. This single component grease is charged with ceramic. This product is available in 225 grammes. For bigger packaging please contact us. We also offer other  thermally conductive adhesives  for high temperature bonding.
Full description
Image générique

Duralco® 135 Thermal Grease

Cotronics Duralco ® 135 is a thermally conductive grease. It is a non-hardening product. It is ideal for use between components and heat sinks. Usable to 260°C. This single component grease is charged with fine aluminium powder. This product is available in 0.12 and 0.23 litres.  For bigger packaging please contact us. We also offer other thermally conductive adhesives for high temperature bonding.
Full description
Image générique

Duralco® 128 Adhesive epoxy

Cotronics Duralco ® 128 adhesive is a bonding epoxy resin. It is used to make high temperature bonding, up to 260°C. This 2 components epoxy adhesive is charged with ceramic. This adhesive is a good electric conductor. This product is available in 0.23, 0.47 and 3.7 grammes. For bigger packaging please contact us. We offer other products that may meet the requirements of your application: Our other  electrically conductive epoxy resin All our  high temperature adhesives  Our  epoxy products
Full description
