High Temperature Ceramic Sleeves 1700°C

Ceramic Sleeves, up to 1,700 °C

Final Advanced Materials can supply an innovative continuous polycrystalline ceramic fibre. The metallic oxides at the heart of its composition ensure that the processing of this fibre into ceramic textiles is particularly simple. The resulting mechanical and thermal performance capabilities exceed those of other fibrous materials, including aramid, silica, quartz or even glass.

Monofilament ceramic sleeves type 080-0500 are composed mainly of Al2O3 and can withstand operating temperatures up to 1,370 °C. They are particularly suitable for the insulation and protection of cables, tubes, pipes and thermocouples. They can also be used as insulation seals.

Applications of Ceramic Fibre Sleeves

  • Thermal and electrical insulation
  • Protection of cables and pipes
  • Reinforcment of manufactured products
  • Thermocouple insulation
  • Heat shield
  • Insulation joints
  • Welding

Technical Data of Ceramic Fibre Sleeves

Property

Unit

Ceramic Sleeves

Item N°

080-0500

080-0510

080-0520

080-0530

080-0540

080-0515

080-0525

Composition

%

Al2O3 : 62.5

SiO2 : 24.5

B2O3 : 13

Al2O3 : 70

SiO2 : 28

B2O3 : 2

Max. Operating Temperature

°C

1,100

1,370

Peak Temperature

°C

1,700

1,700

Thermal Conductivity

at 100 °C

W.m-1.K-1

0.10

0.12

at 500 °C

0.14

0.16

at 1,000 °C

0.18

0.19

Linear Shrinkage, after 15 hrs at 1,300 °C

%

< 1.5

< 0.5

Packaging of Ceramic Fibre Sleeves

Property

Unit

Ceramic Sleeves 1,100 °C

Item N°

080-0500

080-0510

080-0520

080-0530

080-0540

Diameter

mm

1.6

3.2

6.4

12.7

25.4

Thickness

mm

0.71

0.94

0.97

0.97

0.84

Roll Length

m

30

30

15

15

7.5

Property

Unit

Ceramic Sleeves 1,370 °C

Item N°

080-0515

080-0525

Diameter

mm

3.2

6.4

Thickness

mm

0.97

0.89

Roll Length

m

30

15

Other dimensions and cut are available on demand.

Physical variables included in this documentation are provided by way of indication only and do not, under any circumstances, constitute a contractual undertaking. Please contact our technical service if you require any additional information.
