Kevlar® Aramid Fibre Sewing Thread 170°C
Kevlar® Aramid Fibre Sewing Thread, up to 170 °C
The word 'aramid' is a contraction of 'aromatic polyamide'. The chemical name is para phenylene terephthalamide or PPD-T. Created in the 1960’s, aramid fibres consist of yellow filaments of about ten microns in diameter, assembled into threads.
Kevlar® threads can continuously withstand 170 °C. Beyond this, the mechanical and dimensional characteristics decrease (slow carbonisation of the polymer) up to their decomposition temperature of 425 °C. Easier to handle than fibreglass threads, they are used in many technical fields.
Applications of Kevlar® Aramid Thread
- Ballistics (bullet-proof vests)
- Safety shoes
- Protective clothing
- Composite materials
- Airbags
- Air dust extraction filters
- Hot gas filtration
- Tyres (reinforcement)
Technical Data of Kevlar® Aramid Thread
|
Property |
Unit |
Continous Filaments |
|
Item N° |
060-0010 |
|
|
Titel |
tex |
135 |
|
Rupture Force (ISO 2062) |
N |
239.6 |
|
Elongation at Break (ISO 2062) |
% |
3 |
|
Diameter |
mm |
0.51 |
|
Linear Density |
m/kg |
6,570 |
|
Packaging |
coil |
500 g 3,000 m |
|
Property |
Unit |
Discontinuous Filaments |
||
|
Item N° |
060-0020 |
060-0030 |
060-0040 |
|
|
Titel |
tex |
80 |
60 |
40 |
|
Rupture Force (ISO 2062) |
N |
102.5 |
76.7 |
48.0 |
|
Elongation at Break (ISO 2062) |
% |
4 |
4 |
3 |
|
Diameter |
mm |
0.40 |
0.30 |
0.23 |
|
Linear Density |
m/kg |
11,680 |
16,130 |
23,450 |
|
Packaging |
coil |
250 g 3,000 m |
200 g 3,000 m |
125 g 3,000 m |
Storage of Kevlar® Aramid Thread
Aramid yarns must be stored away from UV radiation, in black packaging. Excessive exposure to UV radiation will result in the yellowing of the yarn, and the impairment of its tensile strength.
Recommended Needle Sizes for Kevlar® Aramid Thread
Continuous filaments:
- 060-0010: 130 – 150 Nm
Non-continuous filaments:
- 060-0020: 120 – 140 Nm
- 060-0030: 110 – 130 Nm
- 060-0040: 100 – 120 Nm
Physical variables included in this documentation are provided by way of indication only and do not, under any circumstances, constitute a contractual undertaking. Please contact our technical service if you require any additional information.
