Ceramic Fibre Tapes, up to 1,700 °C
Final Advanced Materials can supply an innovative continuous polycrystalline ceramic fibre. The metallic oxides at the heart of its composition ensure that the processing of this fibre into ceramic textiles is particularly simple. This continuous fibre demonstrates a mechanical and thermal performance that fibrous materials do not achieve, such as aramid, silica, quartz or glass.
The 080-0700 ceramic tapes are resistant to operating temperatures up to 1,100 °C. They are particularly suitable for the insulation and protection of cables, tubes and pipes and to strengthen packaged products.
A Heat Cleaned coated version is available to limit irritations for customized applications as well as flying fibres and the amount of smoke generated during exposure to high temperatures.
Applications of Ceramic Tapes
- Thermal insulation
- Insulation of pipes and exhausts
- Electrical insulation
- Reinforcement of other products
Technical Data of Ceramic Tapes
|
Property |
Unit |
Ceramic Tapes 1,100 °C |
|||
|
Item N° |
080-0700 |
080-0710 |
080-0720 |
||
|
Composition |
% |
Al2O3 : 62.5 |
|||
|
Area Density |
g/m² |
9.6 |
14.0 |
18.6 |
|
|
Width |
mm |
25 |
38 |
51 |
|
|
Thickness |
mm |
0.51 |
0.48 |
0.48 |
|
|
Max. Operating Temperature |
°C |
1,100 |
|||
|
Peak Temperature |
°C |
1,700 |
|||
|
Thermal Conductivity |
at 100 °C |
W.m-1.K-1 |
0.10 |
||
|
at 500 °C |
0.14 |
||||
|
at 1,000 °C |
0.18 |
||||
|
Linear Shrinkage after 15 hrs at 1,300 °C |
% |
< 1.5 |
|||
|
Breaking Strength |
kg/cm |
23 |
|||
1,370 °C tapes are only produced on request.
Physical variables included in this documentation are provided by way of indication only and do not, under any circumstances, constitute a contractual undertaking. Please contact our technical service if you require any additional information.
